Lead Time: 4-6 Weeks
The Special Cabinets are manufactured upon an order.
Advantage:
1. UV lamp for sterilization.
2. Resistant to weak acid and alkali.
3. Adjustable air speed: 9 levels
4. Motorized front window, height adjustable.
5. Microprocessor control system, LED display.
6. With memory function in case of power-failure.
Technical Parameters:
| Model |
FH1000(A) |
FH1200(A) |
FH1500(A) |
FH1800(A) |
| External Size (W*D*H) |
1040*800*2200mm |
1240*800*2200mm |
1540*800*2200mm |
1840*800*2200mm |
| Internal Size (W*D*H) |
820*670*730mm |
1020*670*730mm |
1320*670*730mm |
1620*670*730mm |
| Work Surface Height |
850mm |
| Max Opening |
520mm |
| Air Velocity |
0.3~0.8m/s |
| Noise |
≤68dB |
| Exhaust Duct |
PVC, Standard length: 4 meters. |
| Φ300mm |
| LED Lamp |
8W*1 |
12W*1 |
16W*1 |
16W*1 |
| UV Lamp |
Emission of 253.7 nanometers for most efficient decontamination |
| Blower |
Built-in centrifugal blower; Speed adjustable. |
| Front Window |
5mm toughened glass; Motorized; Height adjustable. |
| Power Supply |
AC220±10%, 60/50Hz; 110±10%, 60Hz |
| Consumption |
400W |
400W |
500W |
500W |
| Material |
Exterior |
Cold-rolled steel with anti-bacteria powder coating. |
| Interior |
High grade melamine board with good acid and alkali resistance function |
| Work Table |
Chemical resistant phenolic resin |
| Stand Accessory |
UV lamp*2, LED lamp, Water tap, Gas tap, Water sink, Base cabinet |
| Total load of 2 waterproof sockets: 500W |
| 4-meter PVC exhaust duct, pipe strap*2 |
| Optional Accessory |
Active carbon filter |
| Gross Weight |
286kg |
317kg |
350kg |
400kg |
| Package |
Main Body |
1190*990*1690 mm |
1390*990*1690 mm |
1690*990*1690mm |
1990*990*1690mm |
| Base Cabinet |
1190*990*980mm |
1390*990*980mm |
1690*970*970mm |
1990*990*980mm |
|
