Glass-washer: BK-LW220
Lead Time: 4-6 Weeks
Features:
* High efficient cleaning system, designed with European reliable pump, optimized spray arm and nozzles, and self-cleaning program;
* Rapid and efficient drying system, designed with independent air heater, HEPA filter and drying process;
* Water heating temperature can reach 99℃, while hot air drying temperature can reach 120℃;
* Professional configuration design—stainless steel for corrosion resistance;reinforced glass window mounted to achieve a clear view on washing process;
* PLC touch screen control with preset 6 programs and 99 cutomized programs
* Safety protection—electronic security door lock to prevent unexpected door opening, water & drying air temperature dual control and equipped with emergency switch.
* Rapid and efficient drying system, designed with independent air heater, HEPA filter and drying process;
* Water heating temperature can reach 99℃, while hot air drying temperature can reach 120℃;
* Professional configuration design—stainless steel for corrosion resistance;reinforced glass window mounted to achieve a clear view on washing process;
* PLC touch screen control with preset 6 programs and 99 cutomized programs
* Safety protection—electronic security door lock to prevent unexpected door opening, water & drying air temperature dual control and equipped with emergency switch.
Specification
|
Model
|
BK-LW120
|
BK-LW220
|
BK-LW320
|
|
Capacity
|
120L
|
220L
|
320L
|
|
Water Consumption/Cycle
|
15L
|
||
|
Inlet Water Pressure
|
0.03~0.8Mpa
|
||
|
Noise
|
≤50dB
|
≤55dB
|
|
|
Material
|
Internal material: SS316, Outer material: SS304
|
||
|
Overall Power Consumption
|
6KW
|
6.5/16.5KW
|
6.5/18KW
|
|
Power Consumption-Water Washing
|
0.75KW
|
1.5 KW
|
|
|
Power Consumption-Water Heating
|
5KW
|
5/15KW
|
|
|
Power Consumption-Drying
|
2.1KW
|
3.6KW
|
|
|
Power Supply
|
AC220V, 50Hz
|
AC220V, 50Hz; 380V, 50Hz
|
|
|
Cleaning Racks
|
1 pcs
|
2 pcs
|
3 pcs
|
|
Standard Cleaning Racks
|
BKIR36*1
|
BKIR36*2
|
BKIR36*3
|
|
Standard Accessories
|
One bucket RBS A 155 leaner (1 L), One bucket RBS A 375 neutralizer (1 L)
|
||
|
Optional Accessories
|
USB interface, printer, cleaning racks
|
||
|
Washer Chamber Size(W*D*H)mm
|
600*629*465
|
600*629*658
|
600*629*820
|
|
External Size(W*D*H)mm
|
960*740*850
|
780*690*1760
|
790*690*1950
|
|
Package Size(W*D*H)mm
|
1100*950*1050
|
1000*850*2100
|
1000*840*2180
|
|
Gross Weight(kg)
|
145
|
330
|
350
|
